Description
Dimensions & Weight
Exterior: 15.6″ D × 8.1″ W × 10.4″ H (396 × 206 × 265 mm)
Test chamber: 6.9″ D × 7.2″ W × 5.2″ H (172 × 184 × 133 mm)
Weight: 17 lbs (7.7 kg)
🛠X‑Ray Tube & Detector
Anode: Silver (Ag), up to 45 kV, 80 µA
Detector: High-performance Si‑PIN semiconductor
🎯 Analytical Performance
Detects 21–22 elements, including all precious metals and key alloying elements
Results comparable to fire assay (within ~â…› karat) and far
🔋 Power & Accessories
Powered via AC adapter or 7.2 V lithium‑ion battery (charges internally)
Standard accessories: spare X‑ray window, adhesive tack, USB cable, software
Optional: 3 mm small‑spot focus, extra battery and charger, locking carrying case
🛡 Safety & Compliance
Closed‑beam design with dual viewing windows for operator and customer safety
Certified CE, RoHS compliant
