Description
Engine & Performance
Engine: CAT® C1.7L turbocharged diesel, 3 cylinders, 1 699 cc
Max Power: 48 gross hp (at 2 800 rpm)
Fuel System: Common-rail direct injection with Diesel Oxidation Catalyst; supports renewable fuels (HVO, GTL, BTL)
Fuel Tank: 51 L (15 gal) capacity
Starter: Electric start
Drive & Suspension
Transmission: Dual 21 cc Hydro‑Gear pumps + 20.6 cu in Parker wheel motors; includes external oil cooler
Ground Speed: 0–12 mph forward; 0–6 mph reverse
Independent Suspension: Front and rear with heavy-duty coil-over shocks; enhances operator comfort and cut consistency
Deck & Cutting
Deck Width: 72″ (183 cm) fabricated iCD™+ cutting deck, triple-configurable (rear discharge, side discharge, mulching)Deck Drive: 2‑belt system
Cutting Height: 1.5″–6″ (3.8–15.2 cm)
Spindles: Hercules™ II cast‑iron, greaseable
Dimensions & Build
Frame: Heavy-duty tubular steel, 6.35 mm wall thickness
Tyres:
Front: 13 × 6.5‑6
Rear: 26 × 12‑12
Dimensions: 89.7″ (L) × 86″ (W) [chute down], 74″ with chute up
Dry Weight: ~2 518 lb (1 158 kg)
PTO: Electric engagement, 450 ft‑lb Warner GT300 clutch
Operator Comfort & Controls
Seat: Premium high‑back suspension seat with armrests, adjustable lumbar & headrest, integrated seat belt
Controls & Display: Multi‑function color display for engine status, rpm, torque, warnings; includes USB Type A & C ports
Deck Lift: Foot‑activated hydraulic lift
ROPS: 105° foldable roll-over protection
